IPX5 IPX6 Water Jet Spray Test Chamber GT-F63
IPX5 IPX6 Water Jet Spray Test Chamber | Horizontal High-Pressure Waterproof Tester Product Introduction Application: This equipment is mainly used to evaluate the performance of products under simulated rain conditions during storage, transportation, and use. It is widely applied to electrical and electronic products, lighting equipment, electrical cabinets, electrical components, automobiles, motorcycles, and their parts. Under simulated rainfall conditions, the equipment tests the physical and other related properties of the products. After testing, the results are assessed to determine whether the product meets the required standards, providing a basis for product design, improvement, verification, and factory inspection. Standards: GB-4208-2008, GB2423.38, IPX5, IPX6 protection levels Key Specifications Model GT-F63-500 GT-F63-1000 Capacity 500L 1000L Inner Chamber Dimensions (W×D×H ) 800×800×800 mm 1000×1000×1000 Outer Cabinet Dimensions ( W×D×H ) 3600×860×1750 mm 3800×1060×1800 Turntable Diameter 400 mm 600mm Turntable Load Capacity chamber 20 kg Number of Spray Nozzles IPX5 nozzle, 1pc; IPX6 nozzle, 1pc (2 in total) Water Exposure Surface Side of the product Distance from Nozzle to Sample 2,500-3,000mm Nozzle Inner Diameter IPX5: φ6.3 mm; IPX6: φ12.5 mm Spray Flow Rate IPX5: 12.5 ± 0.625 (L/min); IPX6: 100 ± 5 (L/min) Pipe Diameter One 1/2" and one 1" high-pressure flexible hose Spray Pressure 30–200 kpa (adjustable according to flow rate) Turntable Speed 1–7 rpm Spray Duration 3, 10, 30, 9,999 min (adjustable) Operation Time Control 1–9,999 min (adjustable) Water Circulation System Ensures continuous recycling of water Spray Pressure Gauge Displays water spray pressure Control System Self-developed touchscreen control system Spray System Composed of water pump, pressure gauge, and fixed spray pipe bracket Spray Pipe Material Stainless steel External Material 304 stainless steel Frame Material 304 stainless steel square tubes, brushed finish
