Chambre d'essai de pluie GT-F60

Rain Test Chamber GT-F61 is a high-precision environmental testing system engineered to evaluate the water-ingress resistance and sealing integrity of automotive lighting, electric motors, electronic components, and electrical enclosures. the GT-F61 integrates vertical drip testing, 15° tilted dripping, oscillating tube rain spraying, and splash testing into a single compact system. Driven by an intuitive LCD touchscreen controller, precision stepper motor oscillating tube control, and smooth gear motor turntable speed regulation, GESTER GT-F61 offers exact test timing (adjustable from 0s up to 99h 59m 59s / 1–999,999 min) and dual flow/pressure monitoring via digital flow meters and stainless steel spring-type pressure gauges. Built with SUS#304 stainless steel, GESTER provides direct factory supply, custom chamber dimensions, fast global delivery.

IPX 123456 Horizontal Rain Spray Test Chamber Product Introduction Application: This equipment is mainly used to test the performance of products during storage, transportation and use under rainy climatic conditions. It is applicable for testing the physical and other related performances of electronic and electrical products, lamps, electric cabinets, electrical components, automobiles, motorcycles and their parts under simulated rainy conditions. After the test, the product performance is verified to judge whether it meets the requirements, so as to facilitate product design, improvement, verification and factory inspection. Standards: GB2423.38-90, GB4706.32-2004, IEC60529, GB4208-2008, etc. Key Specifications Model GT-F62-500 GT-F62-1000 GT-F62-1500 Capacity 500L 1000L 1500L Inner chamber dimension (mm, W×D×H) 800×800×800mm 1000×1000×1000 1500×1500×1500 Outer chamber dimension (mm, W×D×H) 1380×3600×1750 1480×3800×1800 18900×4300×2300 Dripping area dimension (mm, W×D×H) 600×600×60 800×800×60 800×800×80 Distance between water dripping tank and sample chamber 200mm (inside) Dripping hole diameter φ0.4mm Spacing of water spray holes 20mm Rainfall 1±0.5mm/min, 3±0.5mm/min Turntable IPX1: horizontal;   IPX2: tiltable at 15° Air source Prepared by the buyer, air source with pressure above 5kg IP34 Swing pipe radius(mm) 400 600 Distance between spray head and sample 200mm (inside) Spacing of water spray holes 50mm Swing angle range of spray pipe 120°, 320° (configurable) Nozzle included angle IPX3: 120°   IPX4: 180°  Swing pipe speed 30°/s   Swinging speed IP3: 15 times/min; IP4: 5 times/min times/min Water spray hole diameter φ0.4mm Flow rate per water spray hole 0.07(±5%) L/min Water spray pressure 80-150kPa Spray system IPX3: 16 nozzles; IPX4: 25 nozzles Water flow rate IPX3: 1.1 L/min, IPX4: 1.8 L/min IP56 Number of spray heads IPX5 spray head, 1pc;  IPX6 spray head, 1pc (2 in total) Water-receiving surface Side of the product Distance between spray head and sample 2500～3000mm(or within that range) Inner diameter of spray hole IPX5: φ6.3mm, IPX6: φ12.5mm Water spray flow rate IPX5: 12.5±0.625 L/min, IPX6: 100±5 L/min Pipe diameter 1 piece of 1/2 inch high-pressure hose ; 1 piece of 1 inch high-pressure hose respectively Water spray pressure 30～200kPa (adjusted according to flow rate) Continuous water spray time 3, 10, 30, 9999min (adjustable) Running time control 1～9999min (adjustable) Water circulation system Ensures recycling of water source Water spray pressure gauge Displays water spray pressure Flow and pressure control Mechanical flow meter

fournisseurs d'équipements de test de batteries

Testeur d'efficacité protectrice des masques PM. Plus de 20 ans d'expérience en R&D et en vente. Service après-vente irréprochable.

fournisseurs d'équipements de test de batteries

Le cylindre de nettoyage à sec est utilisé pour déterminer la solidité des couleurs au nettoyage à sec et à l’eau de piscine chlorée.

Le but de cet essai est de déterminer : (1) la rétention de la charge (IFD à 65 %), (2) une perte d'épaisseur et (3) une rupture structurelle telle que traitée par inspection visuelle. Cette procédure décrit des tests qui évaluent l'éprouvette en déviant de manière répétée le coussin du tapis par un rouleau recouvert de caoutchouc de 152 mm de diamètre et de 152 mm de largeur, exerçant une force de 266 ± 5 N sur les éprouvettes.

Ce testeur de perméabilité à l'air Schopper a été conçu selon QB/T1667. Il est utilisé pour tester la perméabilité à l'air de matériaux tels que le papier, le sac de ciment, le papier câblé, etc.
